01 · BLOCK
Resolve the block
Type the address. Parcel, zoning, overlays, easements and trees load in seconds.
Siting, design & pricing for home builders · knock-downs · extensions · house & land
Start with the block. Close in the room.
Type an address and the lot loads with every planning rule checked live. Place a home, size it, study the sun, and hand over a priced, compliant proposal — all in the first appointment, while the customer watches.
NO CAD SKILLS · ONE LAPTOP · NO SETUP FEES · RULES RESOLVED TO THE PARCEL
LIVE PRICE$486,200
All clear · 6 checks
✓Side setbacks1.2 m ≥ 1.0 m
✓Garden area28% ≥ 25%
✓Overshadowingclear · 22 Sep
The problem
The deal dies between appointments.
Today, the manual wayManual · disconnected
- −Custom layouts sketched in MS Paint, redrawn in CAD days later
- −Quotes priced by hand, hours later
- −Plan, lot and price in three places
- −Every change is a "let me get back to you"
- −Momentum cools between appointments
With CadastralLive · in the room
- +Every planning rule checked as you drag
- +Re-priced the instant anything changes
- +Block, home, sun and price in one workspace
- +Every change answered on the spot
- +You close while they're still at the table
Five days of follow-up, compressed into thirty seconds in the room.
How it works One spine · five steps
One conversation, five steps. The app keeps count.
Every session walks the same spine. Each step ends with one forward action, and nothing unlocks before it's ready — so a rep always knows where they are and what comes next.
02 · HOME
Choose & size it
Browse designs that fit this block, pick a size and façade, tick the option packs.
03 · SITING
Place it, checked live
The plan snaps to setbacks; every rule is re-checked as you drag, with a remedy for anything that fails.
04 · SUN
Study the sun
Shadows across the day and year, neighbour overshadowing, and light inside the home.
05 · PRESENT
Present & send
Flip to presentation mode, walk the proposal, send the branded PDF before they leave.
Versions, saved state and the live price stay pinned in the top bar the whole way through.
The product
Verdicts, not vibes. Every answer is measurable.
Live compliance
Every check comes with a verdict — and a remedy.
Cadastral doesn't just flag a breach, it tells you exactly how big it is and exactly how to fix it. "Too deep by 0.41 m — slide 1.73 m south to clear." One tap applies the fix, and the whole checklist re-runs. Honest numbers a rep can say out loud to a customer.
Explore live compliance Rear setbacktoo deep by 0.41 m
Slide 1.73 m south to clearFix
TPZ — Corymbia, 14 mencroaches 6%
Under 10% — permit path availableDetails
Front setback4.0 m ≥ 4.0 m · pass
Garden area28% ≥ 25% · pass
Size drives everything
Change the size, and the whole model moves with it.
A selection is a design and a size — never a design alone. Switch the Wexley from 26 to 24 and Cadastral swaps the footprint, re-sites it from the same corner, re-runs every rule, re-prices, and tells you exactly what you gained and lost. In one line, while the customer watches.
Explore size & fit Wexley 24FITS · 1.2 M SPARE Wexley 26FITS · 0.4 M SPARE Wexley 28NEAR MISS · 0.2 M
Wexley 24 — fits with 1.2 m spare · −$18,400
loses bed 4 · 2 façades unavailable
loses bed 4 · 2 façades unavailable
Sun studies
Show them winter light before they sign, not after they move in.
Scrub through the day and the seasons. Three views answer the three questions every buyer has: where the shadows fall, whether the home overshadows a neighbour, and how much light lands in the living room. Cadastral flags an overshadowing breach the moment it happens.
Explore sun studiesShadowsNeighbourInside
JUNE 212:40 PM
Present & price
One live price. Presented, sent, and in your CRM.
Every change re-prices against your actual costing matrix, and one number stays pinned in the top bar — the same number on the quote, the session card and the PDF. Flip to presentation mode for a clean customer-facing view, then send the branded proposal before they've found their car keys.
Explore price & presentBase — Wexley 26 · 4 · 2 · 2$412,900
Halden façade+$14,800
Alfresco 4.2 × 3.0+$18,400
Site costs — 22 Myddleton Dr+$40,100
Total, inc GST$486,200
Send proposal PDFSave to shortlist
Under the hood Scheme text → parcel
Every council planning scheme in Australia, read and resolved to the parcel.
This is the hard part, and it's the part we automated. Cadastral ingests state planning provisions and every council scheme underneath them, extracts the rules that govern a build, and resolves them down to the individual lot — so the setback your rep sees is the setback that applies at that address, not a state-wide average.
The rule engine
A planning scheme is a document. We turn it into a number.
Planning rules live in thousands of pages of scheme text, amendments and overlay schedules — which is why siting has always needed a person. Cadastral reads them: language models extract each provision into a structured, testable rule, our planners review it, and the rule is then resolved against the parcel's zone, overlays and dimensions. The clause becomes "≥ 1.0 m at this address." Every verdict carries the clause it came from.
See it in live compliance Source documentCasey Planning Scheme · cl. 54.02-3AM. C287CASE · 12 MAR 2026
↓ EXTRACT
Structured ruleSide setback — wall height dependent1.0 M, +0.3 M PER M OF WALL OVER 3.6 M
↓ RESOLVE
At 22 Myddleton DrSide setback ≥ 1.0 m · you have 1.2 mGRZ2 · 448 M² · WALL 3.4 M · PASS
79 councils · amendments checked nightly · every verdict cited
Plan import
Your whole catalogue, live in an afternoon.
The reason siting tools never get adopted is onboarding: forty designs sitting in PDFs that someone has to redraw. Cadastral reads them instead. Drop in a plan and it comes back traced, scaled, walls and openings identified, ready to site — you review and publish rather than draft. What used to be a quarter of drafting time is an afternoon of approvals.
Explore plan importWexley 26 · PDF in
→
Traced · to scale
01Scale detected from dimension strings1:100
02Walls, doors and windows identified96% conf.
03Footprint and areas computed232 m²
04Sent to your team to check & publish1 review
AI & assurance
AI automations where it's safe. Deterministic where it counts.
AI takes the admin out of the way — reading scheme text, tracing floor plans and searching thousands of placements in seconds, work that used to take drafting days. The compliance engine then evaluates every rule geometrically and cites the clause, so the speed comes with an answer you can defend: same block, same home, same answer, whoever is holding the laptop.
AI-assisted automations
Reads · extracts · searches
- ◇Reads scheme text and extracts the provision
- ◇Flags amendments that change an existing rule
- ◇Traces a PDF floor plan to scale
- ◇Ranks the catalogue against this block
- ◇Searches for the placement with the most clearance
Rules-based compliance engine
Deterministic · cited
- ✓Pass or fail is evaluated, never inferred
- ✓Every rule is planner-reviewed before a rep sees it
- ✓Setbacks, coverage and sun angles are computed geometrically
- ✓Price comes straight from your costing matrix, untouched
- ✓No verdict without a cited clause
A rep should never have to say "the computer thinks so." Tap any verdict and you get the clause, the scheme and the amendment date behind it — so it survives the customer's next question, and drafting's review.
For your catalogue team
Your catalogue, your rules, your prices.
Reps can only sell what's true. The admin console keeps it that way — designs, sizes, façades and option packs, published to the estates you service, priced from your own matrix. Change a price and every rep sees it next session.
- ✓Designs, sizes & façades with drafts and review
- ✓Floor plan import — read, traced and to scale
- ✓Serviced areas by suburb & postcode
- ✓Option packs & categories, per design
- ✓Pricing via CSV from your estimating system
- ✓Members & roles — owner, admin, sales rep
DesignSizesFaçadesStatus
Wexley
Single storey 23 · 26 3 Published
Single storey 23 · 26 3 Published
Corvelle
Single storey · Lifestyle 24 · 27 2 Published
Single storey · Lifestyle 24 · 27 2 Published
Kelby
Double storey 26 · 29 · 32 4 In review
Double storey 26 · 29 · 32 4 In review
Ravella
Double storey · Designer 31 1 Draft
Double storey · Designer 31 1 Draft
The outcome
Built for the metrics you actually own.
Cadastral is for sales directors who measure first-appointment close rate. If your team can answer the customer's next question before the customer's next coffee, your numbers move.
− 0 days
Average deal cycle, in pilot.
+ 0 %
First-appointment close rate uplift.
0
Callbacks to drafting for siting checks.
ILLUSTRATIVE · BASED ON EARLY PILOT ESTIMATES
"The siting question used to end the appointment. Now it's the moment we win it — we move the plan, the price follows, and nobody has to call drafting."
Who it's for
Built for the sales floor. Not a replacement for your back office.
Cadastral is for builders doing knock-down rebuilds, extensions, renovations and house-and-land — whether that's twenty homes a year or three hundred. It gives your first point of contact the knowledge your architect, draftsperson, estimator and surveyor already hold.
So the customer gets an answer today instead of an appointment next week. It runs on your existing catalogue, costing rules and CRM. You don't need an IT department, and your reps don't need CAD.
